CL/CLT Series
Product Description
IPG Photonics offers CL and CLT Series Cr:ZnSe/S
continuous wave Mid-IR fiber-bulk hybrid lasers.
These lasers provide from 1 to 150 W average
output power at a customer selected fixed
wavelength (CL Series) or 0.2 to 100 W tunable
output (CLT Series) in the range of 1.9 to 3.0 μm.
CL and CLT lasers feature typical narrow linewidth
of less than 0.5 nm. Standard and rapid tuning
options are available. Rapidly tunable (swept)
models allow scanning the entire tuning range
with aquisition rate of up to 1000 spectra per
second. These laser models are designed for
characterizing broad spectral features such as
absorption spectra of polymers.
Technical Specifications
Specification
| Parameter | CL | CL-SR | CLT | CLT-SR |
| Central Wavelength | Customer Selected in 1.9-3.0 µm Range | CV | Tunable in 1.9-3.0 µm Range | |
| Spectral Linewidth, nm | 0.1-2.0, Typ. < 0.5 | |||
| Output Power*, W | 1-10 | 20-150 | 0.1-10 | 10-100 |
| Power Tunability, % | 10-100 | |||
| Wavelength Tuning Options** | N/A | Standard or Rapid (Swept) Tuning Mode | ||
| Beam Diameter (FW, 1/e²), mm | 1.5 ±0.5 | |||
| Beam Divergence, mrad | <5 | 0.1-1, Typ. 0.5 | ||
| Polarization | Random or Linear | Linear, Horizontal >100:1 | ||
| Beam Quality, M² | <1.2, typ. ≤1.1 | |||
| Warm-up Time, min | 5 from Standby, 15 from Cold | |||
| Optical Head Style | CW Fixed or Tunable Module | |||
| Pump Laser*** | IPG Photonics' ELR or TLR CW Fiber Laser | |||
| Pump Laser Dimensions (W × D × H), mm | 448 × 403 × 132 | |||
| Optical Head Dimensions (W × D × H), mm | 165 × 505 × 122 | |||
| Supply Voltage 50-60 Hz, VAC | 110-240 | |||
| Power Consumption, W | 200 Typ. |
