CPXDC-250
Product Description
DIGITAL SYNERGIC CO2/MAG CONTROL
Digital Ammeter & Voltmeter
Easy to read Ampere and Voltage settings.
One-Knob Control
Automatic voltage adjustment that adjusts the Ampere.
Available Wire Modes
0.8/1.0/1.2mm.
Technical Specifications
Specification
| Parameter | Details |
| Model | CPXDC-250 |
| Input Voltage | 220V ±10% or 400V ±15% (selectable) |
| Phase | 3-phase |
| Frequency | 50/60 Hz |
| Rated Input Power | 12.5 kVA (220V) 18.0 kVA (400V) |
| Rated Input Current | 25.9 A |
| Rated Output Current | 250 A |
| Rated Load Voltage | 26.5 V |
| Output Range | 50–250 A / 15–33 V |
| Max No-load Voltage | 51 V |
| Duty Cycle | 60% |
| Temperature Range | –10°C to +40°C (160°C max rise) |
| Dimensions (W×D×H) | 416 × 662 × 770 mm |
| Weight | 103 kg |
| Protection Level | IP21S |
| Compatible Wire | 0.8 mm, 1.0 mm, 1.2 mm |
| Welding Methods | CO₂, MAG |
