Arc Sensor FD-AR
Product Description
Automatic seam tracking by weaving * This sensor alloes correction of curved workpiece or thermal distortion which cant be corrected only by detecting workpiece position. * Applicable to workpieces with medium thickness or thicker. * Most inexpensive among all the tracking sensors. * Easy to use from the viewpoints of interference of workpieces and maintenance because this sensor requires no additional parts around the torch. ** Cant be used for tracking on aluminum.
Technical Specifications
| Workpiece position detection | x |
| Seam tracking | o |
| Recognition of groove shape | x |
| Combination with other sensors | Combination use of the touch sensor and laser sensor is possible |
| Applicable workpieces | Plate thickness: 3.2 mm or more |
| Accuracy | ± 1.0 mm (provided that the arc and pool are stable) |
| Workpiece material | Iron system, stainless steel system |
