ICB-Q21-07-HMI
Product Description
The Angle Battery Modular Nutrunner Tensor ICB-Q is a small, ergonomic and, one-handed tool, specifically designed for cramped area applications. This model, equipped with a Quick-change system, allows the operator to use the correct angle-head (Q2) for every application. This tool also offers the features of the ICB-A family such as a built-in EHMI display, rotating angle head and trigger. Tensor ICB-Q is part of the Tensor IxB Family
Country of origin is SE.
Technical Specifications
Specification
| Specification | Detail |
| Height | 88.6 mm |
| Length | 254 mm |
| Output size | IQ-7 |
| Weight | 2.25 lb |
| Width | 74.6 mm |
| Sound pressure | < 70 dB(A) |
| Sound standard | ISO15744 |
| Vibration standard | ISO28927-2 |
| Vibration value | < 2.5 m/s² |
| CCC certified | No |
| CMIIT ID | 2020AJ14906 |
| EAC certified | Yes |
| EU Legislation | 2006/42/EC (MD); 2011/65/EU (RoHS); 2014/53/EU (RED); 2015/863/EU (RoHS amendment) |
| EU Standard | EN 300 328 V2.2.2; EN 300 440 V2.1.1; EN 301 489-1 V2.1.1; EN 301 489-17 V3.2.4; EN 301 893 V2.1.1; EN 50566:2017; EN 55014-1:2017; EN 55014-2:2015; EN 61000-6-2:2005; EN 61000-6-3:2007+A1; EN 61000-6-4:2007+A1; EN 62841-1:2015; EN 62841-2-2:2015 |
| ETL control number | 3008099 |
| ETL listed | Yes |
| ETL text | 6 - 62841-2-2 |
| EU SAR value | 0.55 W/kg |
| FCC ID | XF6-M7DB7 |
| IC ID | 8407A-M7DB7 |
| KC certified | No |
| UK Regulations | S.I. 2008/1597; S.I. 2012/3032; S.I. 2017/1206 |
| UK Standard | EN 300 328 V2.2.2; EN 300 440 V2.1.1; EN 301 489-1 V2.1.1; EN 301 489-17 V3.2.4; EN 301 893 V2.1.1; EN 50566:2017; EN 55014-1:2017; EN 55014-2:2015; EN 61000-6-2:2005; EN 61000-6-3:2007+A1; EN 61000-6-4:2007+A1; EN 62841-1:2015; EN 62841-2-2:2015 |
| WEEE | 5 - Small equipment <50cm |
| Battery | Li-Io 14/18 V |
| Type of battery | 1 Li-ion |
| Weight incl. battery | 3.04 lb |
| Torque range max | 5.2 ft-lb |
| Torque range min | 1 ft-lb |
| Torque scatter 3s | ≤ 5 % |
| Motor power | 500 W |
| Motor voltage type | d.c. |
| Motor voltage | 35 V |
| Model type | Quick change |
| Output type | Quick change interface |
| Quick change interface | IQ-7 |
| Shut-off system | Transducer |
| Tool family | ICB |
| Speed range max | 1205 r/min |
