W2425
Product Description
These tools feature a lightweight composite housing that can handle though environments but at the same time being easy on the operator. The W29 is equipped with a powerful twin-hammer clutch suitable for the toughest jobs.
Technical Specifications
Specification
| Category | Specification |
| Certifications & Standards | |
| CCC Certified | No |
| CQC Certified | No |
| EAC Certified | Yes |
| EU Legislation | 2006/42/EC (MD), 2011/65/EU (RoHS), 2014/30/EU (EMC), 2015/863/EU (RoHS amendment) |
| EU Standards | EN 61000-6-2:2019, EN 61000-6-4:2019, EN 62841-1:2015+AC:2015, EN 62841-2-2:2014+AC:2015, EN ISO 12100:2010 |
| KC Certified | No |
| UK Regulations | S.I. 2008/1597, S.I. 2012/3032, S.I. 2016/1091 |
| UK Standards | BS EN 62841-1:2015, BS EN 62841-2-2:2014, BS EN IEC 61000-6-2:2019, BS EN IEC 61000-6-4:2019, BS EN ISO 12100:2010 |
| WEEE Compliance | Category 5 (Small equipment <50cm) |
| Dimensions & Weight | |
| CS Distance | 20.5 mm |
| Length | 320 mm (12.6 in) |
| Weight | 1.6 lb (0.73 kg) |
| Design & Functions | |
| Model Type | Straight |
| SCIP Number | 0e839bca-71a3-4a55-89b6-1f31bd7caef9 |
| Shut-off System | Transducer |
| Speed | |
| Max Speed Range | 970 RPM |
| Power | |
| Motor Power | 140 W |
| Motor Voltage Type | 3-Phase AC |
| Motor Voltage | 35 V |
| Torque | |
| Max Torque Range | 5.5 ft-lb (7.46 N·m) |
| Min Torque Range | 1.2 ft-lb (1.63 N·m) |
| Torque Scatter (3σ) | ≤ 5% |
| Noise & Vibrations | |
| Sound Pressure | <70 dB(A) |
| Sound Standard | ISO 15744 |
| Vibration Standard | ISO 28927-2 |
| Vibration Value | <2.5 m/s² |
