AKAS
Product Description
The AKAS system safety guard for press brakes complies with world standards, and has acquired EN954 Category 4 and EN12622
certifications.Since the laser beams surely detect the fingers of the operator, safety is guaranteed, even for operations
in which ensuring safety was difficult with conventional safety devices.
Technical Specifications
Specification
| Input voltage | AC100～220V 50/60Hz 又は DC24V |
| Power consumption | Stationary: 15W or less , Motor running: 35W or less |
| Response time | 11.5ms |
| Output contact | a X 2 |
| Output contact capacity | AC220v_2A, DC30v_2A |
| Optional contact | b X 1 |
| Optional contact capacity | AC24v_1A, DC24v_1A |
| Effective distance | AKAS-3：10m
AKAS-IIF：10m
AKAS-LCII：10m |
| Operating temperature range | 0℃ ～ 50℃ |
| Laser class | Class 1 |
| compliance standards | EN61496-1 (type 4）、EN12622、EN61496-1：2008
IEC61496-2：2006、EN ISO 13849-1：2008、EN 62061：2005 |
