2PF500
Product Description
2-Axes Double Support Positioner 2PF Series * High-speed motion increases production efficiency! An increase in the maximum rotation speed of the tilting axis by 2.5 times and in rotation axis by 2 times was achieved in comparison with the conventional machine 300 kg payload type.
Technical Specifications
| Model Name | A2PF501-ENN |
| Max. Payload Capacity | 500 kg |
| Rotating Speed | 2.8 rad/s (162"/s) |
| Tifling Speed | 1.5 rad/s (84"/s) |
| Rotating Torque | 392 N · m |
| Tifling Torque | 1347 N · m |
| Position Repeatability | ± 0.08 mm (Position at R250 mm) |
| Stop Position | Random |
| Mass (Weight) | 260 kg |
